Xprinter XP-233B black direct thermal barcode label printer top view showing the compact 2-inch sticker printer cover and control area.

Xprinter XP-233B direct thermal label printer close-up showing the paper exit, control button and sticker printing area.

Xprinter XP-233B 2-Inch Direct Thermal Barcode Label Printer - Black

Xprinter XP-233B is a compact 2-inch direct thermal barcode label printer designed for retail labels, stickers, logistics labels and receipt printing. It offers 203 DPI resolution, up to 101 mm/s label printing speed, 20–60 mm media support, TSPL label mode and ESC/POS receipt mode in a black desktop design.

LE 0.00

Compare

Ask a question

Size guide

Share

Xprinter XP-233B 2-Inch Direct Thermal Barcode Label Printer - Black

LE 0.00

Specification	Details
Brand	Xprinter
Model	XP-233B
Product Type	2-Inch Direct Thermal Barcode Label Printer
Color	Black
Material	ABS
Printing Method	Direct Thermal
Print Modes	Label Print Mode and Receipt Print Mode
Print Resolution	203 DPI
Maximum Print Speed - Label Mode	50.8–101 mm/s
Maximum Print Speed - Receipt Mode	90 mm/s
Print Width - Label Mode	56 mm
Print Width - Receipt Mode	48 mm
Media Type - Label Mode	Thermal sticker paper and adhesive paper
Media Type - Receipt Mode	Thermal paper
Media Width - Label Mode	20–60 mm
Media Width - Receipt Mode	58 mm
Media Thickness	0.06–0.08 mm
Media Roll Diameter	Max. 100 mm
Interface Options	USB, USB+Serial or USB+Bluetooth
Sensors - Label Mode	Paper End, Cover Open and Gap Sensor
Sensors - Receipt Mode	Paper End and Cover Open
Drawer Port	1 port, Pin 2 for cash drawer
Input Buffer	4096 Kbytes
NV Flash	4096 Kbytes
Internal Fonts	Font 0 to Font 8
1D Barcode Support	CODE128, EAN128, ITF, CODE39, CODE93, EAN13, EAN8, CODABAR, POSTNET, UPC-A, UPC-E, MSI, PLESSEY, ITF14 and EAN14
2D Barcode Support	QR Code, PDF417 and Data Matrix
Emulation - Label Mode	TSPL
Emulation - Receipt Mode	ESC/POS
Driver Support - Label Mode	Windows
Driver Support - Receipt Mode	Windows, Linux, Mac and Android
SDK Support	iOS, Android and Windows
Power Input	AC 100–240V, 50/60Hz
Power Output	DC 12V / 3A
Print Head Life	50 km
Operating Temperature	0–45°C
Operating Humidity	20–80% RH
Storage Temperature	-40–55°C
Storage Humidity	Up to 93% RH
Certifications	CCC, CB, CE, FCC and RoHS
Dimensions (D × W × H)	190 × 135 × 137 mm
Weight	1.18 kg

Shipping cost is based on weight. Just add products to your cart and use the Shipping Calculator to see the shipping price.

We want you to be 100% satisfied with your purchase. Items can be returned or exchanged within 30 days of delivery.

Features

Compact 2-inch direct thermal printer for barcode labels, stickers and receipt printing.
Supports both label print mode and receipt print mode for flexible retail and logistics use.
203 DPI print resolution supports clear barcodes, text and QR codes.
Prints at up to 101 mm/s in label mode and up to 90 mm/s in receipt mode.
Supports 20–60 mm thermal sticker and adhesive label media.
Interface options include USB, USB+Serial and USB+Bluetooth depending on configuration.
Supports TSPL emulation for label printing and ESC/POS emulation for receipt printing.
Built-in Paper End, Cover Open and Gap sensors support smoother daily operation.
Supports common 1D and 2D barcode formats including QR Code, PDF417 and Data Matrix.
Compact black ABS body fits retail counters, shipping desks and small workspace setups.
